Industrial Vises

CONTINUOUS & RAPID ACTION WOODWORKING VISES

Designed and built to withstand the most severe conditions. The buttress threaded screw and bronze nut are carefully machined so these vises have a continuous screw with rapid action movement. These vises fit flush on a standard 2 1/4” bench top. All woodworking vise jaws are drilled and tapped for easy installation of wood faces if desired. Each vise has a built-in bench dog for added versatility. Available in your choice of wood or aluminum handle.
Meets all Federal Specifications: GGG-V-445 Type I, Class II.

PRODUCT
NUMBER		 ITEM
NO.		 JAW
WIDTH		 JAW
DEPTH		 MAXIMUM
OPENING		 WEIGHT HANDLE
in. mm in. mm in. mm lb. kg
1131800 18A 7 177 4 101 9 228 28 12 WOOD
1131900 18AA 7 177 4 101 9 228 28 12 ALUM
1132800 28A 10 254 4 101 12 304 32 14 WOOD
1132900 28AA 10 254 4 101 12 304 32 14 ALUM


RAPID ACTION WOODWORKING VISES

Designed and built to withstand the most severe conditions. The buttress threaded screw and bronze nut are carefully machined so these vises have a continuous screw with rapid action movement. These vises fit flush on a standard 2 1/4” bench top. All woodworking vise jaws are drilled and tapped for easy installation of wood faces if desired. Each vise has a built-in bench dog for added versatility. Available in your choice of wood or aluminum handle.
Meets all Federal Specifications: GGG-V-445 Type I, Class II.

PRODUCT
NUMBER		 ITEM
NO.		 JAW
WIDTH		 JAW
DEPTH		 MAXIMUM
OPENING		 WEIGHT HANDLE
in. mm in. mm in. mm lb. kg
1141000 100A 7 177 4 101 9 228 28 12 WOOD
1141100 100AA 7 177 4 101 9 228 28 12 ALUM
1142000 200A 10 254 4 101 12 304 30 13 WOOD
1142100 200AA 10 254 4 101 12 304 30 13 ALUM


CONTINUOUS SCREW WOODWORKING VISES

Designed and built to withstand the most severe conditions. The steel screw and nut are carefully machined so they will provide a lifetime of trouble-free service. These vises fit flush on a standard 2 1/4” bench top. All woodworking vise jaws are drilled and tapped for easy installation of wood faces if desired. Each vise has a built-in bench dog for added versatility. Available in your choice of wood or aluminum handle.
Meets all Federal Specifications: GGG-V-445 Type I, Class II.

PRODUCT
NUMBER		 ITEM
NO.		 JAW
WIDTH		 JAW
DEPTH		 MAXIMUM
OPENING		 WEIGHT HANDLE
in. mm in. mm in. mm lb. kg
1131000 10A 7 177 4 101 9 228 29 13 WOOD
1131100 10AA 7 177 4 101 9 228 29 13 ALUM
1132000 20A 10 254 4 101 12 304 34 15 WOOD
1132100 20AA 10 254 4 101 12 304 34 15 ALUM


MILWAUKEE WORKSHOP WOODWORKING VISE

This is a medium duty woodworker vise ideal for small shop or home use. Made of high tensile grey iron, fully machined. Front and back jaws are drilled to allow for easy wood face and bench installation. This vise fits a standard 2 1/4” thick bench top.

PRODUCT
NUMBER		 ITEM
NO.		 JAW
WIDTH		 MAXIMUM
OPENING		 WEIGHT
in. mm in. mm lb. kg
1143000 300A 7 177 7 177 17 7
